Research Field

Optical Design and Interpretation

- LED High, Low beam, Head up display, Automobile of Light Guide, LED Application for lighting, LED Application for TV, Monitor, IT Mobile

Head up Display

Optical Analysis and Installation
Analyzing optical brightness
and distribution plots

Automotive Ambient Lighting

Optical Design and Interpretation
Installation

Development and production
of LED modules

LED High, Low beam, Automobile of Light Guide

LED Heatsink Simulation

Features
  • Convection (default) 10W/㎡℃ at 25℃
  • Heatsink material: 1050A
  • Forward current: type = 1A
  • Forward voltage: type = 6.5V

LED Low/High Beam optics Simulation

Features
  • Type. Color temperature : 5850K
  • Type. Luminous flux : 820 lm at 1A
  • Half viewing angle : 60 °

Architecture,
Interior Space Lighting Optical

2D and 3D implementation with various patterns and lighting to design shapes and sizes of typical to geometric patterns.

2D Pattern

Korean traditional patterns

3D Pattern

Geometric patterns
